Silicone Foamed Battery Pack Gasket
  • Silicone Foamed Battery Pack Gasket
  • Silicone Foamed Battery Pack Gasket
  • Silicone Foamed Battery Pack Gasket
Silicone Foamed Battery Pack Gasket

Silicone Foamed Battery Pack Gasket

Place of Origin China
Brand Name FQ
Certification IATF16949
Model Number BPS-02
Product Details
Material:
Customized
Sized:
Customized
Tape:
Double-sided Adhesive
Requirements For Flame Retardant Grade:
Customized
Appearance Requirements:
Smooth Surface, No Damage, Scratches, Lack Of Material, Obvious Defects And Other Defects
Adhesive:
3M/Nitto
Sample:
Available
OEM:
Avalible
Highlight:

Silicone Foamed Battery Pack Gasket

,

Battery Pack silicone foam gasket

Payment & Shipping Terms
Minimum Order Quantity
Customized
Price
USD 45/PC
Packaging Details
pp bag+Cartons
Delivery Time
1000 pcs/ days
Payment Terms
L/C, T/T, D/P
Supply Ability
1000pcs/day
Product Description
Products Description
F-TECH-FSR370 is a low-stress silicone foamed silicone material. It has a low density and excellent resistance to compression set. Compared with traditional carbon-based foam materials, the material has excellent high and low-temperature resistance (-55-200 °C), high flame retardant (V-0), extremely low smoke density and smoke toxicity. In addition, the material has excellent ageing and weather resistance, making it ideal for all types of shock absorption, cushioning, support, sound insulation, protection, insulation and fire protection.





Main Features
  • Superior flame resistance
  • UV and ozone resistance
  • Extremely resilient to mechanical fatigueLow flame, smoke and toxicity upon combustionExcellent performance at extreme temperaturesSuperior resistance to compression set and creepMeets the most stringent UL flame ratings
Specification
SN TEST UNITES Testing standards Technical indicators
1 Density g.cm-3 ASTM D 1056 0.37±0.04
2 Hardness kPa ASTM D 1056 75 ± 20
3 Compression set % ASTM D 1056 @100℃ ≤ 5.0
4 Tensile strength MPa ASTM D412-16 ≥ 0.3
5 Elongation % ASTM D412-16 ≥ 80
6 Water absorption % ASTM D 570 ≤ 5.0
7 Environmental testing / RoHS,REACH,ELV OK
8 Flame retardant / UL94-2013 V-0
9 Low temperature bending / ASTM D 1056 -55℃OK
10 Dielectric strength kV/mm ASTM D149-09 ≥ 2.5
11 Volume resistivity Ω·cm ASTM D257-14 ≥ 1.0*1014
12 Thermal conductivity W/(m·K) ASTM C518-17 0.08±0.01



Other details

Application
  • Cold supply chain
  • Gap filling
  • Gasketing and sealing
  • Shock absorption
  • Vibration management



Compressive stress curve

Silicone Foamed Battery Pack Gasket 0

Application

Silicone Foamed Battery Pack Gasket 1

Common Industry Applications

  • Telecommunications outdoor enclosures (environmental gasket)
  • Portable data acquisition (gaskets and cushioning)
  • Indoor lighting (dust gasket, UL 94V-0)
  • Outdoor LED lighting (weather gasket, long life, UL listed)
  • Asset tracking (environmental gasket, low compression set)
  • Instrumentation (vibration dampening)
  • Electronics (touch screen gaskets, cushioning)
Package & Delivery

Silicone Foamed Battery Pack Gasket 2
It is a non-dangerous good. Store it in a cool, dry place below 27°C.
